Print
Vitesse d'impression42ppm (A4 single-sided)44ppm (Letter single-sided)70ppm (A5 long edge single-sided)A5 short edge: 9ppm
Duplex print speed20spm（A4）
First Print out time≤5.9s
Printer languagePCL5e、PCL6、PS、GDI
Duplex printingAuto
U-disk printNo
Mobile printAirPrint、Mopria™ Print Service、APP print（iOS /Android APP）
Compatibilité OSMicrosoft Windows：Server2008/Server2012/Server2016/2019/2022/XP/Win7/Win8/Win8.1/Win10/win11（32/64 bit）Mac OS：10.10~14.3Linux Ubuntu 16.04/18.04/20.04/22.04/Debian 10.0/Centos 7（32/64 bit,intel Processor）；Astra Linux Special Edition V1.6/Redhat 8.2.0/ Centos 8.2(64 bit,intel Processor)Android：8.0 and lateriOSAPP：iOS 13 and laterHarmonyAPP：support HarmonyOS 2-4、HarmonyOS NEXT
Other printing fuctionBooklet printing, mute printing, envelope printing without wrinkles,confidential printing, PDF printing
NoteApple, AirPrint Mac and macOS are trademarks of Apple lnc., registered in the U.S and other countries.Use of the Works with Apple badge means that an accessory has been designed to work specifically with the technology identified in the badge and has been certified by the developer to meet Apple performance standards.Mopria makes it easier to print and scan from your Android and Windows.For Android, Mopria™ Print Service and Mopria Scan are available for installation in the Google Play™ store.If you want to get more information, please visit https://www.mopria.orgThe Mopria™ wordmark and the Mopria™ Logo are registered and/or unregistered trademarks of Mopria Alliance, Inc. in the United States and other countries. Unauthorized use is strictly prohibited.
Gestion du papier
Paper input traystandard input tray：250 pages;Multipurpose input tray：60 pages;Optional tray：550 pages (Maximum:2);Max input tray：1,410 pages
Paper output tray150 pages
Paper output full dectationYES
AccessoryPT-511H (Optional tray 550 Pages -Maximum:2)
Types de support1. Automatic paper feeder: plain paper, thick paper, transparent film, thin paper, recycled paper2. Multi-purpose paper feeder: plain paper, thick paper, card paper, label paper, envelope, thin paper, extra thick paper3. Optional paper tray: plain paper, thick paper, thin paper
Format de supportA4, A5, JIS B5, IS0 B5, A6, Letter,Legal,Executive,Folio,Oficio,Statement, Japanese Postcard, Monarch Env, DL Env, C5 Env, C6 Env, No.10 Env, ZL, Big 16K, Big 32K, 16K, 32K, B6, Yougata4, Postcard, Younaga3, Nagagata3, Yougata2Min size：80mm x 148mmMax size：216mm x 356mm
Media weightinput tray：60-120g/㎡Multipurpose tray：60-200g/㎡Optional tray：60-120g/㎡
Général
Control panel2 line LCD
Vitesse processeur1.2G Hz
Mémoire1GB
Hard discNo
Recommended Monthly Duty Cycle750 to 4,000 pages
Maximum Monthly Duty Cycle100,000 pages
Interface"High-speed USB 2.0IEEE 802.3 10/100/1000Base-TxUSB interface: rear USB DEV (1)
Input voltage110V： AC110-127V, 50/60Hz, 13A220V： AC220-240V, 50/60Hz，6.5A
Consommation électriqueprint average：≤650Wready：≤8Wsleep：≤1.4Wshutdown ≤0.5W
Energy Star standardsEnergy Star 3.2
Niveau sonorePrint：≤56dB(A)Ready：≤30dB(A)Mute：≤50dB(A)
Operating EnvironmentRecommended temperature:10～32℃basic used temperature：5～35℃Humidity range：20% ～ 80%Altitude：≤3000m
Consommable
Consumable TypeToner Cartridge & Drum Unit
Starter CartridgeTL-*5220 （3,000 pages）
Starter drum unitDL-*5220 （30,000 pages）
Standard CartridgeTL-*5220 （3,000 pages）TL-*5220H （6,000 pages）TL-*5220X （15,000 pages)
Standard drum unitDL-*5220 （30,000 pages）
Packaging
Printer Dimensions(W*D*H)366*350*260mm
Package Dimensions(W*D*H)452*428*333 mm
Printer net weight（kg)9.3kg (With consumable )
Printer gross weight (kg)11.2kg
Standard Consumable Dimensions(W*D*H)Toner Cartridge：330×447×331mm（3K/6K）356×395×516mm（15K）Drum Unit：361×362×506mm
Standard Consumable Package Dimensions(W*D*H)Toner Cartridge：344*475*375mm（3K/6K）370*423*530mm（15K）Drum Unit：375*390*520mm
Consumables Net weight(kg)Toner Cartridge：0.67kg（3K）0.78kg（6K）1.05kg（15K）Drum Unit：0.47kg（30K）
Consumables gross weight(kg)Toner Cartridge：1.11kg（3K）1.17kg（6K）1.56kg（15K）Drum Unit：0.91kg（30K）
